Description:
1703 Hydraulic Elbow 45° JIC Code61 Flange is a 45-degree elbow male flange adapter with a 74-Degree cone flare JIC thread. And it has a 3000 PSI maximum pressure.
Fluid power and fuel distribution applications typically use JIC (or Joint Industry Council), a hydraulic fitting with parallel threads and a 37-degree flared seating surface.
Please get in touch with us for free samples or more information on sae code 61.
Features and Benefits:
• Strong seal
• Temperature resistance
• Pressure resistance
• No leaks
Categories: JIC, Code 61, Elbow 45°, Carbon steel, Adapter
Part NO. | TUBE | FLANGE | B1 SAE 37 | L | M.M, | M | M.M. | W* | M.M. | C HEX | C HEX | M.M. |
1703-08-08 | 1/2 | 1/2 | 3/4-16 | 1.080 | 27.43 | 1.770 | 44.96 | 0.500 | 12.70 | 13/16 | 0.812 | 20.62 |
1703-12-12 | 3/4 | 3/4 | 1 1/16-12 | 1.500 | 38.10 | 1.650 | 41.93 | 0.560 | 14.22 | 1 1/8 | 1.125 | 28.57 |
1703-12-16 | 3/4 | 1 | 1 1/16-12 | 1.300 | 33.02 | 1.850 | 46.99 | 0.560 | 14.22 | 1 1/8 | 1.125 | 28.57 |
1703-16-16 | 1 | 1 | 1 5/16-12 | 1.400 | 35.56 | 2.200 | 55.88 | 0.560 | 14.22 | 1 3/8 | 1.375 | 34.92 |
1703-20-20 | 1 1/4 | 1 1/4 | 1 5/8-12 | 1.300 | 33.02 | 2.350 | 59.69 | 0.560 | 14.22 | 1 11/16 | 1.687 | 42.85 |
1703-20-24 | 1 1/4 | 1 1/2 | 1 5/8-12 | 1.750 | 44.45 | 2.000 | 50.80 | 0.560 | 14.22 | 1 11/16 | 1.687 | 42.85 |
1703-24-24 | 1 1/2 | 1 1/2 | 1 7/8-12 | 1.600 | 40.64 | 2.300 | 58.42 | 0.620 | 15.75 | 2 | 2.000 | 50.80 |
1703-32-32 | 2 | 2 | 2 1/2-12 | 1.700 | 43.18 | 2.900 | 73.66 | 0.620 | 15.75 | 2 5/8 | 2.625 | 66.68 |
This video describes the 1703 Hydraulic Male JIC Code61 Flange in detail.
Furthermore, 1703 JIC hydraulic flange fittings are available in a variety of applications, sizes, and dimensions, allowing them to be used in a variety of hydraulic fluid systems.
If you have any questions about code 61 flanges, please contact us.
