Brass JIC Flare Fittings

Description:

The brass JIC female 90-degree elbow adapter is an elbow fitting with a male JIC thread and a female NPT thread, it is commonly used in hydraulic systems for piping and hydraulic applications.

The brass JIC flare fittings are designed to connect two tubing sections at a 37-degree angle to provide a secure and leak-proof seal.

If you have any questions about the brass jic hydraulic fittings, feel free to ask.

Features and Benefits:

• Easy to assemble
• Durability
• Leak free
• Strong seal



Description

Part #

Tube OD

Tube Thread

A NPTF

M

N

Working Pressure

28-973

1/4

7/16-20

1/8-27

1.08

0.66

2797 psi

28-974

1/4

7/16-20

1/4-18

1.25

0.55

3066 psi

28-975

3/8

9/16-18

1/4-18

1.23

0.88

2842 psi

Brass JIC Flare Fittings- Female Forged Elbow Video

This video shows information about brass JIC flare fittings – female forged elbow.

We can offer different sizes and types of  JIC brass adapter, such as 1/2, 1/4, 3/8, etc. These JIC fittings play an essential role in fluid systems.

If you have any questions about jic to npt brass elbow, please contact us.
