Caravan Double Acting Telescopic Hydraulic Cylinder

Double Acting Telescopic Hydraulic Cylinder

Caravan Double Acting Telescopic Hydraulic Cylinder

Outer Barrel: The outer barrel serves as the main body of the telescopic cylinder, providing the foundational structure and housing the inner stages.

Inner Stages: These are nested barrels that extend and retract within the outer barrel, allowing for a longer stroke in a compact form factor.

Piston: The piston is located in the last stage and is responsible for initiating the extension and retraction of the inner stages.

Piston Rod: This rod is connected to the piston and extends or retracts as hydraulic fluid is pumped into or out of the cylinder.

Rod Gland: Located at the opposite end of the base cap, the rod gland provides a pathway for the piston rod to move while maintaining a tight seal.

Seals: Specialized seals are used at each stage to prevent hydraulic fluid from leaking, ensuring efficient operation.

Bearings or Bushings: These reduce friction between the piston rod and the rod gland, as well as between the telescopic stages, enhancing the cylinder’s lifespan.

Stop Rings: These are used to limit the extension of each stage, preventing over-extension and potential damage.

Description

First off, what sets this cylinder apart is its telescopic design. Unlike standard hydraulic cylinders, this one features multiple stages that extend and retract within each other. This allows for a longer stroke while maintaining a compact size, making it ideal for caravans where space is at a premium.

Applications

Construction Equipment: For machinery requiring a long reach.
Material Handling: In forklifts and cranes.
Agricultural Machinery: For specialized tasks like soil tilling.

Advantages

Space Efficiency: Its compact design is perfect for applications with limited space.
Versatility: Suitable for a wide range of applications.
Durability: Built to last, even under demanding conditions.

Topa's Customized Services

Feel free to reach out for more information or to discuss how our customized Caravan Double-Acting Telescopic Hydraulic Cylinders can benefit you. We’re here to provide top-notch solutions that align perfectly with your requirements.

Custom Hydraulic Cylinders

Consultation and Design
The process begins with a detailed consultation to understand your specific needs. Whether you require a cylinder with a unique stroke length, load capacity, or mounting options, our team of skilled engineers will draft a design that incorporates all your specifications.

Material Selection
Quality is our top priority, and that starts with the materials we use. We select high-grade steel and specialized seals to ensure that your custom cylinder can withstand the rigors of caravan life, from constant movement to varying weather conditions.

Precision Manufacturing
Our state-of-the-art manufacturing facilities are equipped to produce cylinders with the utmost precision. Each component is meticulously crafted to meet the design specifications, ensuring a final product that not only meets but often exceeds industry standards.

Caravan Double Acting Telescopic Hydraulic Cylinder

At Topa, we offer a comprehensive, end-to-end manufacturing process that prioritizes quality, precision, and customer satisfaction. From the initial consultation and meticulous design phase to the careful selection of high-grade materials, state-of-the-art manufacturing, rigorous quality assurance, and robust after-sales support, we are committed to delivering hydraulic cylinders that meet the highest standards of excellence.

Feel free to reach out for more information or to discuss how Topa’s manufacturing process can meet your specific needs. We’re here to provide top-notch solutions that align perfectly with your requirements.
