Description

Part Number | Thread inch | Hose I.D inch | A | H inch | B | ||
inch | mm | inch | mm | ||||
10171-6-6 10171-8-8 10171-12-8 | 3/8×18 1/2×14 3/4×14 | 3/8 1/2 1/2 | 2.36 2.82 2.67 | 60 72 68 | 3/4 7/8 1-1/16 | 1.47 1.63 1.47 | 37 41 37 |
10171-12-12 10171-16-12 10171-16-16 | 3/4×14 1×11-1/2 1×11-1/2 | 3/4 3/4 1 | 3.08 3.08 3.63 | 78 78 92 | 1-1/16 1-3/8 1-3/8 | 1.71 1.72 2.04 | 43 44 52 |
10171-20-16 10171-20-20 10171-24-20 | 1-1/4×11-1/2 1-1/4×11-1/2 1-1/2×11-1/2 | 1 1-1/4 1-1/4 | 3.49 4.06 3.77 | 89 103 96 | 1-11/16 1-3/4 2 | 1.90 2.39 2.10 | 48 61 53 |
10171-24-24 10171-32-32 | 1-1/2×11-1/2 2×11-1/2 | 1-1/2 2 | 4.32 4.66 | 110 118 | 2 2-1/2 | 2.19 2.52 | 56 64 |
10171 NPT One Piece Crimp Hose Fittings Video
The NPT one piece crimp hose fittings manufacturing process video gives you a better understanding of Topa’s factory and level of expertise.
As the video unfolds, you will see the entire process of china one piece hose fitting from raw material cutting to completion. We use the highest quality carbon and stainless steel and specialized automated processes to ensure our products meet your standards.
Ready to experience quality service? Visit Topa today to learn more about our line of premium hydraulic fittings. Let Topa help you make a better choice.
